MTU 4000 12-16V Diesel Engine Crankcase Ventilation Removal Guide

This instruction show you guide on how to remove crankcase ventilation for MTU 4000 12-16V diesel engine.



Related Contents:

2022 MTU DiaSys 2.74 2.72 Engine Diagnostic Software Free Download

MTU Diagnostic Tool USB-to-CAN



Procedures:

Release clamps (1) and fit rubber sleeve (3 ) over remaining pipe end (2).

Note:Dismantling refers to engine side, left and right.

MTU-4000-12-16V-Diesel-Engine-Crankcase-Ventilation-Removal-Guide-1

Release clamps (2) and fit rubber sleeve (1) over remaining pipe end (3).

Remove piping system.

Note:Dismantling refers to engine side, left and right.

MTU-4000-12-16V-Diesel-Engine-Crankcase-Ventilation-Removal-Guide-2

Release clamps (arrow) and fit rubber sleeves over remaining pipe.MTU Engine USB to CAN diagnostic adapter

Unscrew hex screws (2), remove clamps with oil separator (1) and spacer sleeves.

MTU-4000-12-16V-Diesel-Engine-Crankcase-Ventilation-Removal-Guide-3

Unscrew hex sockets (1) and remove piping system (2), left engine side.

MTU-4000-12-16V-Diesel-Engine-Crankcase-Ventilation-Removal-Guide-4

Unscrew hex sockets (1) and remove piping system,right engine side.

MTU-4000-12-16V-Diesel-Engine-Crankcase-Ventilation-Removal-Guide-5

Disconnect piping system (2) at T-piece.

Remove pipe clamp halves (1), disconnect line (3) at partition area (4) and remove.

MTU-4000-12-16V-Diesel-Engine-Crankcase-Ventilation-Removal-Guide-6

MTU DiaSys 2.73 Diagnostic Software Installation Service

Remove pipe clamp halves (2), disconnect line (1) at partition area to oil pan and remove.

MTU-4000-12-16V-Diesel-Engine-Crankcase-Ventilation-Removal-Guide-7

Unscrew hex screw (1), withdraw sleeve (2) from oil separator and remove.

Note: Sleeve is not included in scope of delivery of new oil separator.

MTU-4000-12-16V-Diesel-Engine-Crankcase-Ventilation-Removal-Guide-8

Note: After removal, seal all connections with suitable plugs.
