ZF Transmission Nissan Failure Number 005,006,007 Repair Guide

This instruction show you guide on how to repair Japan Nissan vehicle ZF transmission failure number 005,006,007.

ZF Transmission on Nissan Differential Speed Trouble Repair Guide

Related Contents:

ZF Testman Pro 10.5 Transmission Diagnostic Software Free Download



ZF Failure number: 005

Failure description: Error on “Rear axle, right wheel speed”

Failure detection: CAN-Signal Error Indicator

ZF-internal name: e_vRearRight_ERR

ZF-internal type: DI_ET_INVALID_SIGNAL

System reaction: ErrorLevel 1

Failure reset condition: No Failure Signal

If failure reset condition is fulfilled: System reaction is reset after ignition off

Signal path: CAN connection, ABS, EDC

Pertained component: CAN connection, ABS, EDC



Steps to repair:

Failure Number: 005 e_vRearRight_ERR

Step 1:Check CAN connection,if CAN connection work well.

Yes,go to step 2

No,repair CAN connection



Step 2:Check ABS sensor,if it work well

Yes,go to step 3

No,repair ABS sensor



Step 3:Check EDC





ZF Failure number: 006

Failure description: Error on “Rear axle, left wheel speed”

Failure detection: CAN-Signal Error Indicator

ZF-internal name: e_vRearLeft_ERR

ZF-internal type: DI_ET_INVALID_SIGNAL

System reaction: Error Level 1

Failure reset condition: No Failure Signal



If failure reset condition is fulfilled:

Signal path: CAN connection, ABS, EDC

Pertained component: CAN connection, ABS, EDC



Steps to repair:

Failure Number: 006 e_vRearLeft_ERR

Step 1:Check CAN connection,if CAN connection work well.

Yes,go to step 2

No,repair CAN connection



Step 2:Check ABS sensor,if it work well

Yes,go to step 3

No,repair ABS sensor



Step 3:Check EDC



ZF Failure number: 007

Failure description: Error on “Front axle, right wheel speed”

Failure detection: CAN-Signal Error Indicator

ZF-internal name: e_vRearRight_ERR

ZF-internal type: DI_ET_INVALID_SIGNAL

System reaction: ErrorLevel 0

Failure reset condition: No Failure Signal

If failure reset condition is fulfilled: System reaction is reset after ignition off

Signal path: CAN connection, ABS, EDC

Pertained component: CAN connection, ABS, EDC



Steps to repair:

Failure Number: 007 e_vRearRight_ERR

Step 1:Check CAN connection,if CAN connection work well.

Yes,go to step 2

No,repair CAN connection



Step 2:Check ABS sensor,if it work well

Yes,go to step 3

No,repair ABS sensor



Step 3:Check EDC
