How to Replace Cabin Air Filter for 2015 Mercedes-Benz GLK350

This instruction will show you guide on how to replace cabin air filter for 2015 Mercedes-Benz GLK350. The cabin filter is located on the passenger side of the vehicle, under the glove box.

How-to-Replace-Cabin-Air-Filter-for-2015-Mercedes-Benz-GLK350-7



Time: 30-60 minutes

Tab: $23 to $50

Talent: 1

Tools: T20 Torx driver, rag

Parts Required: New air filter

Hot Tip: Place a cloth under the filter when removing

Performance Gain: Breathing cleaner air

Complementary Modification: Change engine air filter



Steps:

Use a T20 Torx bit remove the three Torx screws that secure the foot panel to the glove box assembly.

How-to-Replace-Cabin-Air-Filter-for-2015-Mercedes-Benz-GLK350-1

Pull the flooring backwards so you can remove the sealing panel easier

How-to-Replace-Cabin-Air-Filter-for-2015-Mercedes-Benz-GLK350-2

Remove the footwell ceiling panel

How-to-Replace-Cabin-Air-Filter-for-2015-Mercedes-Benz-GLK350-3

The filter is secured by a plastic lock and sometimes metal clips on either end. Pry those off it.

How-to-Replace-Cabin-Air-Filter-for-2015-Mercedes-Benz-GLK350-4

Slide the plastic lock to the left to drop the filter.

How-to-Replace-Cabin-Air-Filter-for-2015-Mercedes-Benz-GLK350-5

Remove the old filter from the housing and clean out any debris inside.

Install you new AQ 1161 C filter into the housing with its air flow indicating arrow pointing towards the back of the car.

Slide securing plastic over the housing tabs to lock it.

How-to-Replace-Cabin-Air-Filter-for-2015-Mercedes-Benz-GLK350-6

Reinstall other parts, replacement is finished.

Recommended replacement every 15,000 miles or one year, refer to your vehicle owners manual for specifications.
