Chevrolet Cruze Sensing & Diagnostic Module (SDM) Programming Guide

This article share the guide on how to program SDM for Chevrolet Cruze online.



Information:

Vehicle model:Chevrolet Cruze

Year:2014

Device:X431 PAD III

Click for more about Chevrolet Cruze Trouble Repair Case

Procedures of SDM Programming:



Step 1:Connect the X431 PAD III to vehicle,then select “Online Programming”

how to program SDM for Chevrolet Cruze online-1

Step 2:Select “GM V49.15″==>Select “Cruze SDM Programming”

how to program SDM for Chevrolet Cruze online-2 how to program SDM for Chevrolet Cruze online-3



Step 3:If system prompt “Download Configure File” show as below

how to program SDM for Chevrolet Cruze online-4

Click to download and if it support the vehicle model software will show as

how to program SDM for Chevrolet Cruze online-5

If it can not support vehicle,the screen will show as blow:

how to program SDM for Chevrolet Cruze online-6

And if the part doesn’t match,screen will show as below:

how to program SDM for Chevrolet Cruze online-7

Step 4:If it can support the vehicle model,then click “YES”.Then software will check the ID,if both of them are consistent,the screen show:

how to program SDM for Chevrolet Cruze online-8

Then click “Confirm”,then just quit software.It mean do not need to program for SDM.

And if ID is inconsistent with standard value,you need to program SDM

how to program SDM for Chevrolet Cruze online-8

Step 5:Click “Confirm” to start programming.

how to program SDM for Chevrolet Cruze online-10

Step 6:After completing programming,follow the prompt info to turn ignition off and wait for about 30s,then turn ignition on.

how to program SDM for Chevrolet Cruze online-11

Step 7:Then back to step 3 to perform “Configuration and seting”



Done!
