MUT-III ECU Variant Coding Writing Function Guide

Here is a guide on how to use MUT-III diagnostic software to do ECU variant coding writing for Mitsubishi cars.



Preparations:

2020 MUT-3 MUT-III Mitsubishi Diagnostic Software Free Download

MUT-III ECU Rewrite ROM Data from 2009 to 2021





Procedures:

Procedure of Variant Coding Writing

(1) Save a coding data into the fixed directory (*1) by

-To read the coding data out of the ECU

Mitsubishi Old ECU Data Reading by MUT-III Diagnostic Software

or

-To obtain a variant coding file in advance

*1: the fixed directory

“C:¥MUTSW_SE¥MUT3_SE¥CdgData¥”

(2) Input a chassis No. or a VIN to list up applied coding files and click button.

MUT-III-ECU-Variant-Coding-Writing-Function-Guide-1

Note:

If coding file is not found in the folder, left screen may appear. In such case, click “Back”button. Save the correct file in the folder and try again

MUT-III-ECU-Variant-Coding-Writing-Function-Guide-2

(3) The applied coding files by the inputted are displayed.

Choose a coding file to be written and click button.

-The background color of the line containing the selected file changes into yellow.

— select a directory

— delete the files

MUT-III-ECU-Variant-Coding-Writing-Function-Guide-3

(4) The current ECU coding data and the coding data to be written are displayed. Click “OK”button if OK.

MUT-III-ECU-Variant-Coding-Writing-Function-Guide-4

(5) Confirmation dialog box appears.

Click “OK”button

MUT-III-ECU-Variant-Coding-Writing-Function-Guide-5

Note:

-In case of ETACS, “ETACS customize” and “Option

Coding” are initialized after writing variant coding.

Rewrite them after finishing coding.

-It is not need that “Option Coding” is executed because the data of “Option coding” includes in variant coding data, if “Copy Coding” was executed.

(6) Completion dialog box is appears.

Click “OK”button

MUT-III-ECU-Variant-Coding-Writing-Function-Guide-6

(7) Written coding data is displayed. Check if the coding data was written correctly.

Click “Back”button

MUT-III-ECU-Variant-Coding-Writing-Function-Guide-7
